Vedanta Aluminium, one of the leading manufacturers and suppliers from Mumbai, India, is known to produce and supply high-quality Aluminium 7050 sheets and plates. Its superior strength and corrosion resistance have made it popular among various industrial markets with superior-grade aluminium solutions. Using modern manufacturing techniques and strict quality checks, Vedanta provides global-standard sheets and plates in every shipment. The firm’s determination to innovate and satisfy customers has established it as a reliable leader in the Indian aluminium industry. For aerospace, automotive, or marine use, Vedanta Aluminium supplies long-lasting and trustworthy Aluminium 7050 products as per client requirements.
Aluminium 7050 is an aircraft-strength alloy consisting mostly of zinc (approximately 6.2%), magnesium (2.3%), and copper (2.3%), together with minute amounts of chromium, iron, and silicon for performance enhancement. This alloying composition provides Aluminium 7050 with superior mechanical properties such as a tensile strength of around 510 MPa and yield strength of around 440 MPa. Its hardness is normally in the order of 150 HB. Resistant to stress corrosion cracking and possessing good toughness, Aluminium 7050 plates and sheets are heat-treatable, offering higher strength and endurance well-suited for severe structural uses.
Standards : ASTM B209 / ASME SB209
Temper : T3,T4,T5, T6, T651 T6511
Thickness : 0.2-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Weight % | Zn | Cu | Mg | Zr | Fe | Si | Mn | Ti | Cr | Others(total) |
| Minimum | 5.7 | 2.0 | 1.9 | 0.08 | – | – | – | – | – | – |
| Maximum | 6.7 | 2.6 | 2.6 | 0.15 | 0.15 | 0.12 | 0.10 | 0.06 | 0.04 | 0.15 |
| Material | Temper | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation in 2″ % |
| Aluminium Alloy 7050 Angle (AMS 4340) | T76511 | 79 | 69 | 7 |
| Aluminium Alloy 7050 Angle (AMS 4340) | T73511 | 70 | 60 | 8 |
| Aluminium Alloy 7050 Angle (AMS 4342) | T74511 | 73 | 63 | 7 |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| UNS | EN | DIN,WNr | ISO |
| A97050 | EN3982 | 3.4144 | AlZn6CuMgZr |
Yes, we offer custom sizes for Aluminium 7050 Sheets and Plates to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Aluminium 7050 plates and sheets from Vedanta Aluminium are used extensively in the aerospace, aviation, and defence industries because of their high strength-to-weight ratio and enhanced corrosion resistance. These characteristics fit them well for aircraft structural parts, fuselage skins, and wing panels. The alloy also finds application in marine environments in shipbuilding and offshore facilities. Its superior fatigue resistance enables it to find applications in automotive components and sports equipment with high performance. Vedanta’s Aluminium 7050 solutions cater to industries that need light and strong materials, balancing strength with reliability for high-stakes engineering applications.
