Vedanta Aluminium, located in Mumbai, India, is a prominent producer and distributor of excellent quality aluminium products, such as Aluminium 5083 Chequered Plates. Renowned for precise production, uniform quality, and international standards of quality, Vedanta Aluminium supplies international customers and is known to be a trustworthy Aluminium 5083 Chequered Plates producer in UK. These plates are manufactured with cutting–edge facilities and subjected to thorough quality inspections to guarantee excellent performance. Based on a robust distribution network and customer-centric strategy, Vedanta Aluminium supplies hard-wearing and corrosion-resistant chequered plates adequate for various industrial, marine, and structural applications in the UK market.
As a reliable Aluminium 5083 Chequered Plates manufacturer in UK, Vedanta Aluminium supplies products with an optimally balanced chemical composition primarily of aluminium (≥ 93%), magnesium (4.0–4.9%), and manganese (0.4–1.0%), with trace levels of chromium, silicon, and iron. These plates have superior mechanical properties in the form of high tensile strength (270–345 MPa), yield strength (145–290 MPa), and good elongation properties. Their superior corrosion resistance, especially in marine and severe industrial exposures, and excellent weldability and fatigue strength properties make them a choice for heavy structural applications needing long-term performance.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H116,H321
Thickness : 0.5-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
| Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5083 Chequered Plates to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Vedanta Aluminium is a renowned UK Aluminium 5083 Chequered Plates manufacturer that provides products to find extensive application in various industries. The plates are specifically appreciated in shipbuilding, marine engineering, oil rigs, and offshore constructions due to their corrosion resistance and high strength. Their chequered structure gives them anti-slip properties and can be perfectly used for ramps, walkways, truck beds, floors, and stairs. They also have applications in aerospace parts, pressure vessels, and transportation infrastructure. Due to their balance of mechanical properties and light weight, they are also selected for architectural applications where both strength and visual appeal are crucial.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
