Vedanta Aluminium, a well-respected manufacturer and supplier located in Mumbai, India, is known for its high-performance aluminium products, including Aluminium 5083 Angles. With top-notch production facilities and rigorous quality control measures, Vedanta guarantees that its aluminium products offer exceptional strength, corrosion resistance, and durability. Aluminium 5083 Angles are particularly popular for their outstanding performance in marine, structural, and industrial settings. Catering to a variety of industries such as shipbuilding, transportation, infrastructure, and defense, Vedanta Aluminium has earned a solid reputation for reliability, innovation, and a consistent supply of top-quality aluminium solutions, both in India and on the global stage.
Aluminium 5083 is an alloy made mostly of 4.0–4.9% magnesium, 0.4–1.0% manganese, and traces of chromium, which further improves its corrosion resistance and strength. Vedanta Aluminium‘s 5083 Angles have superior mechanical properties like a tensile strength of about 290 MPa and a yield strength of 145 MPa. The alloy has high fatigue strength, good weldability, and good resistance to seawater and industrial chemicals. These mechanical properties make it a suitable option for heavy-duty jobs where strength, toughness, and durability are essential.
Standards : ASTM B221 / B211 ASME SB221 / SB211, EN573, EN485, AMS 4003, AMS 4102
Temper : O,H12,H14,H16,H18,H19,H22,H24
Standard : ASTM, ASME, AMS, GB/T, JIS
Thickness : 50 mm to 6000 mm Long
Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Length : 1 To 6 Meters, Custom Cut Length
Finish : Mill, Customer specific finish
Surface : Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
| Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | WNr | UNS | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | 3.3547 | A95083 | AlMg4,5Mn |
Aluminium 5083 Angles are mainly made up of aluminium (about 93–95%), with important alloying elements like magnesium (4.0–4.9%), manganese (0.4–1.0%), and small amounts of chromium and iron. This alloy is known for its excellent corrosion resistance, especially in marine environments, and it maintains high strength even after welding. Its mechanical properties include a tensile strength ranging from 270–350 MPa, yield strength between 130–200 MPa, and elongation of 10–20%, depending on the temper. Aluminium 5083 is a non-heat-treatable alloy celebrated for its remarkable mechanical performance and durability, even under tough environmental and structural conditions.
Yes, we offer custom sizes for Aluminium 5083 Angles to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Aluminium 5083 Angles find extensive use in industries that demand high strength and corrosion resistance. They are perfect for marine applications like ship frames, hulls, and offshore platforms due to their ability to resist saltwater corrosion. In construction, they serve as structural supports in bridges, towers, and architectural frameworks. The transportation sector utilizes them in trailers, railcars, and truck bodies, while defense applications include vehicle armor and protective enclosures. Their weldability, strength, and durability also make them ideal for heavy-duty frameworks, storage tanks, and various industrial
Our team is ready to assist you. Contact us for any queries or personalized solutions.
