Vedanta Aluminium, a top Aluminium 5005 Sheets and Plates producer in India, is known for providing high–quality aluminium solutions to customers in Mumbai and more. Empowered by the principles of quality, accuracy, and innovation, Vedanta Aluminium provides a comprehensive list of aluminium products tailored to industrial, commercial, and architectural needs. Supported by state-of-the-art plant facilities and stringent quality checks, the company ensures that every product conforms to global standards. Their Aluminium 5005 plates and sheets are popularly used for their high corrosion resistance, workability, and smooth surface, making Vedanta a renowned name among Indian aluminium suppliers and manufacturers.
Being a leading Aluminium 5005 Sheets and Plates manufacturer in India, Vedanta Aluminium creates alloys with the majority of them being aluminium (around 97.5%) along with magnesium (0.5% to 1.1%) added to increase strength and corrosion resistance. This alloy is characterized by tensile strength of 170–215 MPa and good elongation and formability. It has high fatigue strength, medium static strength, and good weldability in its mechanical properties. These attributes make Aluminium 5005 perfect for structural use and decoration. Vedanta guarantees every sheet and plate to meet international standards, offering consistency, toughness, and performance in every application.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
|
Element |
% |
Element |
% |
|
Aluminium |
Balance |
Manganese |
0.20 max |
|
Magnesium |
0.50 – 1.10 |
Chromium |
0.10 max |
|
Silicon |
0.30max |
Zinc |
0.25 max |
|
Iron |
0.07 max |
Others, each |
0.05 max |
|
Copper |
0.20 max |
Others, total |
0.15 max |
|
Temper |
0.2% Proof Stress, MPa min† |
Tensile Strength, MPa |
Elongation % min‡ |
|
O (annealed) |
35 |
105 – 145 |
12 – 22 |
|
H12 |
95 |
125 – 165 |
2 – 8 |
|
H14 |
115 |
145 – 185 |
1 – 6 |
|
H16 |
135 |
165 – 205 |
1 – 3 |
|
H18 |
– |
> 185 |
1 – 3 |
|
H32 |
85 |
115 – 160 |
3 – 9 |
|
H34 |
105 |
135 – 180 |
2 – 7 |
|
H36 |
125 |
160 – 200 |
1 – 4 |
|
H38 |
– |
> 180 |
1 – 4 |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| Standard | UNS | ISO | BS | DIN |
| 5005 | A95005 | AlMg1 | N41 | 3.3315 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Yes, we offer custom sizes for Aluminium 5005 Sheets and Plates to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Vedanta Aluminium, a trusted Aluminium 5005 Sheets and Plates supplier in India, supplies materials utilized in numerous diverse industries. Its exceptional corrosion resistance and perfect anodizing finish make Aluminium 5005 suitable for marine environments, architectural claddings, signboards, appliances, and transport systems. Its high strength-to-weight ratio and formability render it applicable in roofing, curtain walls, and interior paneling. The weldability of the alloy also lends itself to application in structural structures, pressure vessels, and food processing equipment. Vedanta‘s Aluminium 5005 plates and sheets are relied upon for their performance, leading to durable, visually appealing, and structurally intact applications in various industries.
