Based in Mumbai, India, Vedanta Aluminium is a well-known producer and supplier of Aluminium 5005 Chequered Plates. Vedanta Aluminium is well-known for producing high-quality aluminium products and serves a variety of Indian and foreign industries. Their Aluminium 5005 Chequered Plates are perfect for industrial and architectural applications because of their exceptional corrosion resistance, robustness, and visual appeal. Vedanta Aluminium has established itself as a reputable leader in the aluminium sector by guaranteeing dependable supply, competitive pricing, and customer satisfaction through the use of sophisticated manufacturing technology, a highly qualified workforce, and stringent quality controls.
The main component of Aluminium 5005 Chequered Plates is aluminium (roughly 97.5–99.5%), with trace amounts of iron, silicon, copper, manganese, chromium, zinc, and magnesium (0.5–1.1%). Particularly in industrial and marine settings, these plates show exceptional resistance to corrosion. Mechanical characteristics include elongation of approximately 12–16%, yield strength of approximately 65–105 MPa, and tensile strength of approximately 170–215 MPa. Excellent workability, moderate strength, and good weldability are all provided by aluminium 5005. It is ideal for wall cladding, flooring, and other structural applications where strength and aesthetics are important due to its decorative finish and non-slip surface.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | DIN,WNr |
| A95005 | – |
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm (%) | |||
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6mm | ||||
| 5005 | 0 | 95-145 | – | 18 | 20 | 21 | 22 |
| 5005 | H12 | 125-170 | 80 | 4 | 5 | 6 | 8 |
| 5005 | H14 | 145-185 | 100 | 3 | 3 | 5 | 6 |
| 5005 | H18 | 185 min | 165 | 1 | 2 | 3 | 3 |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5005 Chequered Plates to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Applications requiring corrosion resistance, lightweight characteristics, and an eye-catching finish frequently use aluminium 5005 engraved plates. These plates offer a long-lasting, non-slip surface and are frequently used for walkways, stair treads, bus and truck bodies, and flooring in industrial facilities. Because of their smooth surface and superior anodising quality, they are used in architectural applications for wall panels, cladding, and decorative facades. They are used in the marine industry for shipbuilding components and boat decks. To satisfy the unique requirements of customers in the industrial, transportation, and construction sectors, Vedanta Aluminium offers Aluminium 5005 Chequered Plates in a range of sizes and finishes.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
