Vedanta Aluminium is a prominent Mumbai-based company manufacturing and supplying high-quality Aluminium 2024 Sheets and Plates exported from the UK. Exemplifying uncompromising standards and precision quality, Vedanta Aluminium provides superior-grade products specially designed to suit various industrial demands. Powered by the core values of quality, strength, and customer satisfaction, the organization supplies aluminium solutions to various industries. The Aluminium 2024 Sheets and Plates offered by Vedanta Aluminium have a very high strength-to-weight ratio, good corrosion resistance, and machinability, and thus are best suited for the most critical applications in the aerospace, automotive, and engineering sectors.
Aluminium 2024 Sheets and Plates, being produced in the UK and distributed by Vedanta Aluminium, mainly have aluminium alloyed with copper (approximately 3.8–4.9%), magnesium, and manganese. This makes it higher in strength and fatigue resistance. Mechanical properties are a tensile strength of around 470 MPa, yield strength of about 325 MPa, and good elongation (around 10-15%). Good machinability and moderate corrosion resistance, usually enhanced by protective coatings, are notable in the alloy. These features qualify Aluminium 2024 for challenging structural applications with requirements for a high strength-to-weight ratio.
Standards : ASTM B209 / ASME SB209
Temper : O, T3,T4, T6, T651
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Sheet/ Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Sheet
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Yes, we offer custom sizes for Aluminium 2024 Sheets and Plates to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Our team is ready to assist you. Contact us for any queries or personalized solutions.
