Vedanta Aluminium is a prominent producer and provider of high-quality Aluminium 2014 Flat Bars in Mumbai, India. It is renowned for its higher strength and good machinability, and the flat bars find extensive application in different industrial applications. Vedanta Aluminium provides precision engineering and international quality standards in the manufacturing process. The company has a strong supply chain infrastructure and caters to both domestic and overseas markets effectively. Clients opt for Vedanta due to their dependable service, prompt delivery, and reasonable prices. Their Aluminium 2014 Flat Bars are perfect for usage in applications where high strength and superior performance in stress are needed.
Aluminium 2014 Flat Bars consist mainly of aluminium (90.7–93.5%) with copper (3.9–5%), manganese (0.4–1.2%), magnesium (0.2–0.8%), and other trace elements. The bars have superior strength and hardness, particularly after heat treatment. Its mechanical properties are tensile strength of 450 MPa, yield strength of 390 MPa, and elongation of about 10%. Aluminium 2014 has good fatigue resistance, moderate corrosion resistance, but good machinability, and hence it can be used in heavy duty structural work. The alloy is a heat-treatable wrought aluminium alloy employed for high-performance engineering applications.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 2014 Flat Bars to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Aluminium 2014 Flat Bars find extensive application in aerospace, military, automotive, and engineering industries for their superior strength-to-weight ratio and good machinability. They are utilized in aircraft fittings, structural parts, and frames in the aerospace industry. Engine components, wheels, and suspension parts use them in the automotive industry. They are appreciated for their fatigue and endurance properties in marine and military uses. Moreover, Aluminium 2014 Flat Bars are employed in die making, precision machining, and tooling. These can sustain harsh conditions and hence become the first choice for applications demanding utmost care and high stress with the need for substantial structural support.
