Vedanta Aluminium is a prominent Aluminum 1060 Hex Bars manufacturer and supplier in Mumbai, India, known for supplying superior quality aluminium products to a wide range of industries. With world-class production units and following international standards, Vedanta Aluminium provides precision, strength, and reliability in all products. Being a renowned name in the non-ferrous metal industry, the company is a specialist in the manufacture of Aluminium 1060 hex bars, which possess good conductivity as well as corrosion resistance. Having a wide client base spread across India, Vedanta Aluminium is dedicated to innovation, quality, and timely supply, and therefore, is the first choice for aluminium solutions.
Vedanta Aluminium’s Aluminium 1060 Hex Bars consist of 99.6% pure aluminium, which carries superior electrical conductivity and corrosion resistance. The general composition of the alloy contains minute amounts of iron, silicon, copper, and manganese. Mechanically, they have a tensile strength of 60–100 MPa and yield strength of about 30 MPa, with excellent elongation of 35%. They have a density of 2.7 g/cm³ and high thermal conductivity and are hence well-suited for applications involving good weldability and formability. They are applicable to both industrial and commercial fabrication needs.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 1060 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.15 – 0.20 | 0.10 – 0.15 | 0.01 – 0.03 | 0.01 – 0.03 | 0.01 – 0.05 | 0.01 – 0.03 | 0.020 – 0.030 | 99.60 |
| Mechanical Properties – Al 1060 | ||||||
| Alloy | Temper | UTS(Mpa) | % Elongation | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||
| 1060 | O | 55 | 75 | 25 | 25 | 30 |
| H12 | 75 | 110 | 6 | 6 | 7 | |
| H14 | 90 | 120 | 5 | 5 | 6 | |
| H16 | 95 | 130 | 4 | 4 | 4 | |
| H18 | 130 | — | 3 | 3 | 3 | |
Density : 2.7 g/cm³
Melting point : 649°C (1200°F)
Elastic modulus : 70-80 GPa (10152-11603 ksi)
| STANDARD | UNS |
| Aluminium 1060 | A91060 |
Vedanta Aluminium based in Mumbai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 1060 Hex Bars to meet specific project needs. Our team at Vedanta Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@vedantaluminium.co.in
Vedanta Aluminium’s Aluminium 1060 Hex Bars are extensively used in a variety of industries because of superior electrical conductivity and resistance to corrosion. Typical applications range from electrical busbars, heat exchangers, chemical plant equipment, signages, and kitchenware. Their excellent formability enables applications in cold forming and machining operations, whereas the light weight has applications in transportation and aerospace sectors. They are also popularly used in architectural work in decorative trim and structure. Whether utilized in industrial production or high-performance electrical applications, Vedanta Aluminium’s 1060 hex bars deliver dependable performance, durability, and value in all uses.
